So, you might’ve caught my previous two blog posts where I explained on implementing an ABI compliance reporting system for PostgreSQL as a BuildFarm module. The initial approach involved cloning the PostgreSQL source code and looping through commits to pinpoint the exact commit responsible for any ABI breakage.

But, after discussing with the community on the hackers list(here), a few key issues came to light:

  1. The original approach didn’t quite align with how the other BuildFarm modules functioned.
  2. Looping through commits introduced potential complications, especially when dealing with commits where source compilation might fail. Handling these edge cases would’ve added unnecessary complexity.
  3. Identifying the commit causing ABI breakage is usually pretty straightforward. Since the module typically runs on one or more BuildFarm animals, the number of commits between runs is small enough to easily spot the culprit.

These points led to a shift in how the module actually works. Let’s call it ABI Compliance Reporting V2!

ABI Compliance Reporting V2

BuildFarm animals usually run on cron jobs, triggering the run_build.pl script at set intervals. This script compiles and tests the source code for the latest commit. Interestingly, the BuildFarm client script clones the PostgreSQL source for a specific branch into the $branch_root/pgsql directory. Then, it copies the source (excluding the .git directory) to a separate location. This prevents the configure script from interfering with Git operations when generating configuration files.

So, by leveraging the $branch_root/pgsql Git directory, I can grab the latest tag for that branch using git -C ./pgsql describe --tags --abbrev=0.

Here’s the new workflow:

  1. Store the latest tag: The module stores the latest tag in the $abi_compare_root/$pgbranch/latest_tag file.
  2. Checkout the tag: Check out the stored tag.
  3. Copy the source: Copy the source code (without the .git directory).
  4. Compile: Compile the source code.
  5. Generate ABI XMLs: Store the generated ABI XMLs in $abi_compare_root/$pgbranch/$latest_tag/xmls/.

For subsequent runs, the module checks if the latest_tag file exists. If it does, it assumes the corresponding XMLs are also present. It then directly uses the binaries from the latest commit and compares their XMLs with the most recent tag’s XMLs to generate a report.

Currently, the abicheck directory (or $abi_compare_root, which houses all run-related files for this module) looks like this:

abicheck.lucario/
└── HEAD
    ├── diffs
    │   ├── libpq.so-REL_18_BETA1-HEAD.log
    │   └── postgres-REL_18_BETA1-HEAD.log
    ├── latest_tag
    ├── logs
    ├── REL_18_BETA1
    │   ├── build_logs
    │   │   ├── build.log
    │   │   ├── configure.log
    │   │   └── install.log
    │   ├── pgsql/...
    │   ├── inst/...
    │   └── xmls
    │       ├── ecpg.abi
    │       ├── libpq.so.abi
    │       └── postgres.abi
    └── xmls
        ├── ecpg.abi
        ├── libpq.so.abi
        └── postgres.abi
  • HEAD represents the current branch.
  • REL_18_BETA1 is the latest tag.
  • The xmls directory contains the ABI XMLs generated for the current commit.
  • The diffs directory holds the ABI diffs between the latest commit build and the latest tag.
  • Inside the REL_18_BETA1 directory, the xmls directory contains the ABI XMLs generated for the latest tag.

I’ve also added support for meson and msvc build systems!(Yes, I copied the code from the run_build.pl script :P)

If you want to check the latest source for the module, you can find it on this GitHub pull request and to test it you may use the following command.

perl ./run_build.pl --nosend --verbose --only-steps="configure make make-doc install abi_comp-check" --nostatus --keepall

In the past weeks, I’ve also been trying to remove the Git CLI dependency from my module, as other modules also use it. However, it seems BuildFarm renames the branch it’s working with to bf_$branch_name. Apparently, The bf_ prefix dates back to the dark days of history when Postgres used CVS and when git was adopted, there was a switchover period when both could be used, so the same naming scheme is still being used :) - according to the BuildFarm maintainers.

What’s on the horizon?

  • If a commit is itself a tag, store its XMLs permanently.
  • Remove unnecessary files, respecting the --keepall option.
  • Disallow execution if Git isn’t being used.
  • Inquire about allowing the head branch.
  • Compare from the base commit of the branch if no latest tag is found.

Thanks for reading!
